HUB, WHEEL, TIRE
ITEM PART NUMBER QTY DESCRIPTION 600HDS
1 527GF-10A 2 SPINDLE WITHOUT FLANGE
2 527GF-11 2 RACE, STAINLESS SLEEVE
3 527GF-6A 2 GREASE SEAL 3.38” OD
4 527GF-1 2 HUB BEARING, LARGE
5 527GF-8 2 RACE, LARGE
6 527GF 2 HUB WITH RACES
7 527GF-9 2 RACE, SMALL
8 527GF-2 2 HUB BEARING, SMALL
9 527GF-5 2 WASHER
10 527GF-3 2 CASTLE NUT AND RETAINER
11 527GF-4A 2 BUDDY HUB
12 560B08475 2 CAPSCREW
13 560N08L 2 LOCK NUT
14 527GF-7PA 12
HUB STUD .563” SPLINE ø
15 527GF-7B 12 LUG NUT, ALUMINUM WHEEL
16 522JT2 2 COTTER PIN
17 503CAP 2 GREASE CAP
18 527HC 2 WHEEL (NOT SHOWN)
19 527KCA 2 TIRE (NOT SHOWN)
20 A527GFB 2 HUB, SPINDLE END UNIT ASSEMBLY WITHOUT FLANGE
21 527GF-18 1 O RING, LARGE
22 527GF-19 2 O RING, SMALL
61780 0221
