Barber SURF RAKE 600HD - Hub, Wheel, Tire, Brakes

HUB, WHEEL, TIRE, BRAKES
ITEM PART NUMBER QTY DESCRIPTION 600HDS
1 527GF-10A 2 SPINDLE WITHOUT FLANGE
2 527GF-11 2 RACE, STAINLESS SLEEVE
3 527GF-6A 2 GREASE SEAL 3.38” OD
4 527GF-1 2 HUB BEARING, LARGE
5 527GF-8 2 RACE, LARGE
6 527GF-12 2 DRUM WITH RACES, BEARINGS AND SEAL
7 527GF-9 2 RACE, SMALL
8 527GF-2 2 HUB BEARING, SMALL
9 527GF-5 2 WASHER
10 527GF-3 2 CASTLE NUT AND RETAINER
11 527GF-4A 2 BUDDY HUB 2441
12 509H 2 LOCK NUT
13 504J 2 CAPSCREW
14 527GF-7A 12 LUG NUT
15 522JT2 2 COTTER PIN
16 503CAP 2 GREASE CAP
17 527HA 2 WHEEL (NOT SHOWN)
18 527KCA 2 TIRE (NOT SHOWN)
19 527GF-13 - LEFT BRAKE ASSEMBLY (NOT SHOWN)
20 527GF-14 - RIGHT BRAKE ASSEMBLY (NOT SHOWN)
21 527GF-15 -
LEFT HUB, SPINDLE END UNIT AND BRAKE ASSEMBLY,
COMPLETE
22 527GF-16 -
RIGHT HUB, SPINDLE END UNIT AND BRAKE ASSEMBLY,
COMPLETE
6
-
11
a
61780 0221
