LIFT ARM AND TRIP MECHANISM
ITEM PART NUMBER QTY DESCRIPTION 600HDS
1 526 1 TIE BAR
2 523S 2 SET COLLAR
3 524M 1 LIFT ARM ASSEMBLY
4 523AS01 2 SPROCKET (RIGHT SHOWN)
5 508RG 2 GREASE NIPPLE
6 545NN-1 4 PIN
7 523EHD 2 PIN
8 522JT2 2 COTTER PIN
9 545JJH 2 HYDRAULIC CYLINDER
10 545NN 2 PIN
11 502P 6 COTTER PIN
12 545JJF 2 HYDRAULIC CYLINDER
13 545JJFP 2 PACKING FOR 545JJF
14 545JJHP 2 PACKING FOR 545JJH
15 545JJCA 1 SAFETY SUPPORT
16 545JJCF 1 PIN
17 207CM07 1 SNAP PIN
18 503CAP 10 GREASE CAP
19 560B09175 2 CAPSCREW
20 503S 2 HEXNUT
61780 0221
