Barco ClickShare CX-20 Gen2 User Manual

15R5900114 /01 ClickShare CX-20 Gen2
The white ring on the Button is filling up. When totally filled up it goes to static white and is ready to share
or it starts blinking to indicate that you have to start clickshare.exe on your computer.
On your laptop a new drive appears.
Different situations are possible now:
• Nothing installed, LED ring fills up and starts flashing, indicating that the executable needs to be
started by the user. Double-click the ClickShare application.
• For Windows environment: when connected to internet, driver will be installed and the executable will
be started by the driver.
• For Mac environment: CD-ROM drive will appear, open it and launch the application to get started.
• A launcher or the ClickShare desktop app is preinstalled on your laptop (downloaded from the Base
Unit or Barco website, or deployed company-wide by your IT department). ClickShare is immediately
available.
In the meanwhile a Preparing the meeting room... window is displayed.
Image 2–3
2. The application is started
When the system is ready for use, the share window appears with the message Ready to share to
<ClickShare name>
Image 2–4
The LEDs of the Button are static white.
Getting started

Barco ClickShare CX-20 Gen2 Specifications

General

Resolution	Up to 4K UHD (3840x2160) @ 30Hz
HDMI CEC	Yes
Wireless Technology	IEEE 802.11 a/b/g/n/ac
Video Outputs	HDMI
Audio	Via HDMI
Operating System Compatibility	Windows, macOS, Chrome OS, Android, iOS
Security	WPA2
Video input	HDMI
USB	USB-C
Ethernet	10/100/1000 Mbps
Local view	Available
Network connection	Wi-Fi, Ethernet
Wireless presentation	Yes
Maximum resolution	4K UHD (3840 x 2160)
Operating temperature	0°C to +40°C (+32°F to +104°F)
Storage temperature	-20°C to 60°C
