Barco ClickShare CX-20 Gen2 User Manual

37R5900114 /01 ClickShare CX-20 Gen2
Image 2–50 Audio setup
2.15 Pairing
Pairing of the Buttons with the Base Unit
To be able to use a Button it should be assigned to the Base Unit you are using. This process is called pairing.
All Buttons will need to be updated and paired before use.
In case you buy additional Buttons or when a Button should be assigned to another Base Unit, the Button
needs to be paired (again). The Button software update runs in the background and will not impact users while
using the system. When downgrading or updating to an older version of the Base Unit software the Button
need to paired manually to update their software.
A Button can only be paired to one Base Unit at a time.
The Button will always make connection to the Base Unit it was last paired to.
To pair a Button to the Base Unit by plugging in
1. Insert the Button in the USB type-C
TM
port available on the Base Unit you are using.
Image 2–51 Pair Button
The Base Unit LED is blinking while the Button LED fills up a circle. This means pairing is in progress.
The Base Unit automatically checks whether the software of the Button is up to date. If not, the Base Unit
updates the Button software. This may take more time.
Getting started

Barco ClickShare CX-20 Gen2 Specifications

General

Resolution	Up to 4K UHD (3840x2160) @ 30Hz
HDMI CEC	Yes
Wireless Technology	IEEE 802.11 a/b/g/n/ac
Video Outputs	HDMI
Audio	Via HDMI
Operating System Compatibility	Windows, macOS, Chrome OS, Android, iOS
Security	WPA2
Video input	HDMI
USB	USB-C
Ethernet	10/100/1000 Mbps
Local view	Available
Network connection	Wi-Fi, Ethernet
Wireless presentation	Yes
Maximum resolution	4K UHD (3840 x 2160)
Operating temperature	0°C to +40°C (+32°F to +104°F)
Storage temperature	-20°C to 60°C
