Barco DP2K-12C - Page 166

R5905752 /16 DP2K C166
RS232 IN
4 - 9 -
5 GND Signal Ground (GND) - -
General Purpose IN/OUT
General Purpose In/Out
1 3D Input Reference P 20 3D Input Reference N
2 3D Display Reference P 21 3D Display Reference N
3 GPIN 3 P (reserved) 22 GPIN 3 N (reserved)
4 GPIN 4 P (reserved) 23 GPIN 4 N (reserved)
5 GPIN 5 P 24 GPIN 5 N
6 GPIN 6 P 25 GPIN 6 N
7 GPIN 7 P 26 GPIN 7 N
8 GPIN 8 P 27 GPIN 8 N
9 3D Output Reference P 28 3D Output Reference N
10 GPOUT 2 P (reserved) 29 GPOUT 2 N (reserved)
11 GPOUT 3 P (reserved) 30 GPOUT 3 N (reserved)
12 GPOUT 4 P 31 GPOUT 4 N
13 GPOUT 5 P 32 GPOUT 5 N
14 GPOUT 6 P 33 GPOUT 6 N
15 GPOUT 7 P 34 GPOUT 7 N
16 GPOUT 8 P 35 GPOUT 8 N
17 reserved 36 reserved
18 reserved 37 reserved
19 reserved
Ethernet port
10/100 Base-T — RJ45 port 1000 Base-T — RJ45 port
Pin Pair Color
Description Description
1 3 white/green TXD+ TX0+
2 3 green TXD- TX0-
3 2 white/orange RXD+ RX0+
4 1 blue — TX1+
5 1 white/blue — TX1-
6 2 orange RXD- RX0-
7 4 white/brown — Rx1+
8 4 brown — RX1-
Pin configurations
