automatically and do not require calibration to work properly.
Light adjustment
The lights and LED´s of the EC-200 are confugurable for brighntess. In the Settings Menu page of the interface under
User Pref´s.
Event Master Series Controller Operation
Operation overview
7. Destinations — These buttons give direct selection of the assigned Destination configurations. Buttons toggle on
and off the selection. A blue LED indicates selected
8. Layers These buttons give direct selection of the layers in the selected Destinations. In normal mode the button
selects and/or adds a layer in the Preview of the selected Destination. A green LED indicates selected.
In LIVE mode (unlocked Program) the Layer is selected in the Program of the selected Destination.
9. Assign — These buttons give direct selection of the assigned resources. There are several that can be mapped.
PRESETS The Presets created in Event Master Toolset can be mapped onto an Assign buss for instant recall
Select PRESET via the assign buss function button to have access to mapped presets
USER KEYS User Keys created in EMT can be mapped onto an Assign buss for instant recall. Select USER KEY
via the assign buss function button to have access to mapped user keys.
SOURCES The Source Files, (not the Inputs) created in EMTS can be mapped onto a bus that is selected to
SOURCES, like the bottom row in the picture.
