BACKGROUND SOURCES — The Backgrounds created in EMTS can be mapped onto a bus that is selected to
BackGround Source, this is not shown in the picture.
10. Arrow buttons — These buttons choose the next page of its button bus.
11. Contextual Display Buttons — These provide mapping of a variety of functions from the EMTS.
Mapping of them is done in the menu.
12. Layerfunction Buttons — These buttons provide indicated function to selected layer(s).
14. Cut & All Trans — These buttons executes the transition setup in the GUI.
15. Assign Button Type — These buttons toggles thru the available assign button type.
LEDs
Blue indicates resource is selected
Green indicates the resource is selected in Preview
Red indicates the resource is either on Program, or is transitioning.
Backlight
Once a Button is assigned with a resource, Buss LCD backlights will change color based on the selected function.
– White for Presets
– Magenta for User Keys
– Yellow for Layer Sources
– Green for Background sources
For detailed installation instructions, refer to Chapter “Controller Configuration of the User’s Guide.
Event Master Series Controller Operation

Barco Event Master Series Specifications

General

Category	Controller
Modular Design	Yes
4K Support	Yes
Redundancy	Yes
Dimensions	Varies by model
Weight	Varies by model
Series	Event Master
Inputs	Varies by model
Outputs	Varies by model
Processing	Varies by model
Power Supply	Redundant, hot-swappable
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 60°C
