7. Important information
Power management
DPMS
Dot clock 165 MHz
OSD languages English, French, German, Spanish, Italian, Dutch, Japanese, T raditional
Chinese, Simplified Chinese, Korean
Dimens ions with stand (W x H
xD)
507 x 377–457x 166 mm
Dimensions w/o stand (W x H
xD)
507 x 306 x 57 mm
Dimensions packaged (W x H
xD)
610 x 505 x 230 mm
Net weight with stand 6.7 kg
Net weight w/o stand
4.3 kg
Net weight packaged with
stand
10.1 kg
Height adjustment range 80 mm
Tilt
0° / +20°
Swivel -30° / +30°
Pivot
N/A
Mounting standard
VESA (75 m m)
Screen protection Protective, non-refl ective glass cover
Certifications CE (MDD 93/42/EEC class I product), CE - 2004/ 108/EC, IEC
60950-1:2005 + A1:2009 (2ND EDITION), IEC 60601-1 2ND ED:1988
+ A1:1991 + A2:1995, UL 60601-1 1ST EDITION, CAN/CSA-C22.2
NO. 601.1-M90:2005, IEC 60601-1:2005 + A1:2012, ANSI/AAMI
ES 60601-1:2005 + C1:2009 + A1:2012, CAN/CSAC22.2 No.
60601-1-08:2008, DEMKO - EN 60601- 1:2006, EN 60601-1-2:2007,
CCC - GB9254-2008 + GB4943-2001 + GB17625.1-2003, KC, VCCI,
FCC class B, ICES-001 Level B, FDA Class I device, RoHS
User Guide
Cable routing strap
Cleaning cloth
Video cables (1 x VGA + 1 x HDMI)
Main cables (UK, European (CEBEC/KEMA) or USA (UL/ CSA; adaptor
plug NEMA 5-15P) or Chinese (CCC))
USB 2.0 cable
Supplied accessories
External power supply (model: BridgePower Corp. BPM060S12F15;
Input: 100-240 V AC, 50-60 Hz, 1.5 A; Output: +12V DC (
), 5.0 A)
Optional accessories N/A
QA software QAWeb Private Practice, QAWeb Enterprise
Warranty 3 years
Operating temperature 10°C - 40°C
Storage temperature -20°C - 60°C
Operating humidity 30% - 75% (non-condensing)
Storage humidity 5% - 85% (non-condensing)
Operation altitude 2000 m
Storage altitude 7500 m
Operating pressure 70 kPa - 106 kPa
Storage pressure 50 kPa - 106 kPa
36 K5903049 EONIS 19/02/2014
