Bard MEGA-TEC W120AP - Resistance

Manual 2100-671
Page 38 of 44
Temperature Resistance
F C Ω
-25 -31.7 148,452.94
-24 -31.1 143,910.37
-23 -30.6 139,521.46
-22 -30.0 135,280.55
-21 -29.4 131,182.22
-20 -28.9 127,221.25
-19 -28.3 123,392.63
-18 -27.8 119,691.54
-17 -27.2 116,113.37
-16 -26.7 112,653.66
-15 -26.1 109,308.15
-14 -25.6 106,072.72
-13 -25.0 102,943.44
-12 -24.4 99,916.50
-11 -23.9 96,988.26
-10 -23.3 94,155.21
-9 -22.8 91,413.97
-8 -22.2 88,761.30
-7 -21.7 86,194.07
-6 -21.1 83,709.29
-5 -20.6 81,304.06
-4 -20.0 78,975.60
-3 -19.4 76,721.24
-2 -18.9 74,538.41
-1 -18.3 72,424.61
0 -17.8 70,377.48
1 -17.2 68,394.70
2 -16.7 66,474.07
3 -16.1 64,613.46
4 -15.6 62,810.82
5 -15.0 61,064.17
6 -14.4 59,371.62
7 -13.9 57,731.32
8 -13.3 56,141.52
9 -12.8 54,600.50
10 -12.2 53,106.64
11 -11.7 51,658.35
12 -11.1 50,254.11
TABLE 8
8301-089 Sensor: Temperature/Resistance
Temperature Resistance
F C Ω
13 -10.6 48,892.46
14 -10.0 47,571.97
15 -9.4 46,291.29
16 -8.9 45,049.09
17 -8.3 43,844.12
18 -7.8 42,675.14
19 -7.2 41,540.99
20 -6.7 40,440.51
21 -6.1 39,372.62
22 -5.6 38,336.26
23 -5.0 37,330.40
24 -4.4 36,354.06
25 -3.9 35,406.29
26 -3.3 34,486.17
27 -2.8 33,592.81
28 -2.2 32,725.36
29 -1.7 31,883.00
30 -1.1 31,064.92
31 -0.6 30,270.36
32 0.0 29,498.58
33 0.6 28,748.85
34 1.1 28,020.48
35 1.7 27,312.81
36 2.2 26,625.18
37 2.8 25,956.98
38 3.3 25,307.60
39 3.9 24,676.45
40 4.4 24,062.97
41 5.0 23,466.62
42 5.6 22,886.87
43 6.1 22,323.22
44 6.7 21,775.16
45 7.2 21,242.23
46 7.8 20,723.96
47 8.3 20,219.91
48 8.9 19,729.65
49 9.4 19,252.76
50 10.0 18,788.84
Temperature Resistance
F C Ω
51 10.6 18,337.51
52 11.1 17,898.38
53 11.7 17,471.09
54 12.2 17,055.30
55 12.8 16,650.65
56 13.3 16,256.82
57 13.9 15,873.48
58 14.4 15,500.34
59 15.0 15,137.09
60 15.6 14,783.44
61 16.1 14,439.11
62 16.7 14,103.83
63 17.2 13,777.34
64 17.8 13,459.38
65 18.3 13,149.70
66 18.9 12,848.07
67 19.4 12,554.26
68 20.0 12,268.04
69 20.6 11,989.19
70 21.1 11,717.51
71 21.7 11,452.79
72 22.2 11,194.83
73 22.8 10,943.45
74 23.3 10698.45
75 23.9 10,459.65
76 24.4 10,226.90
77 25.0 10,000.00
78 25.6 9778.81
79 26.1 9563.15
80 26.7 9352.89
81 27.2 9147.86
82 27.8 8947.93
83 28.3 8752.95
84 28.9 8562.79
85 29.4 8377.31
86 30.0 8196.39
87 30.6 8019.91
88 31.1 7847.74
Temperature Resistance
F C Ω
89 31.7 7679.76
90 32.2 7515.86
91 32.8 7355.94
92 33.3 7199.88
93 33.9 7047.59
94 34.4 6898.95
95 35.0 6753.88
96 35.6 6612.28
97 36.1 6474.05
98 36.7 6339.11
99 37.2 6207.37
100 37.8 6078.74
101 38.3 5953.15
102 38.9 5830.51
103 39.4 5710.75
104 40.0 5593.78
105 40.6 5479.55
106 41.1 5367.98
107 41.7 5258.99
108 42.2 5152.53
109 42.8 5048.52
110 43.3 4946.91
111 43.9 4847.63
112 44.4 4750.62
113 45.0 4655.83
114 45.6 4563.20
115 46.1 4472.67
116 46.7 4384.19
117 47.2 4297.71
118 47.8 4213.18
119 48.3 4130.55
120 48.9 4049.77
121 49.4 3970.79
122 50.0 3893.58
123 50.6 3818.08
124 51.1 3744.26
125 51.7 3672.07
