Bard W42HC-A - Table 16 Indoor Blower Performance

Manual 2100-711C
Page 40 of 45
TABLE 16
Indoor Blower Performance
E.S.P.
1
(In. H
2
O)
Balanced Climate
TM
Speed
Default LO Cooling &
Heating/Ventilation
Speed
2
Optional MED
Cooling & Heating
Speed
Optional HI Cooling
& Heating Speed
Dry Coil Wet Coil Dry Coil Wet Coil Dry Coil Wet Coil Dry Coil Wet Coil
W42HC
0.00 1205 1065 1575 1460 1745 1640 1815 1690
0.10 1050 955 1485 1400 1665 1560 1740 1630
0.15 980 900 1440 1360 1625 1520 1705 1600
0.20 915 845 1400 1325 1585 1485 1665 1570
0.25 1360 1280 1550 1450 1630 1535
0.30 1315 1235 1510 1415 1590 1500
0.40 1240 1140 1435 1345 1515 1430
.050 1165 1030 1360 1275 1435 1355
W48HC
0.00 1320 1270 1745 1665 1895 1800 1985 1860
0.10 1225 1160 1700 1615 1850 1760 1915 1810
0.15 1180 1110 1675 1585 1825 1735 1880 1780
0.20 1130 1060 1650 1555 1795 1705 1845 1755
0.25 1615 1520 1765 1675 1815 1720
0.30 1580 1480 1735 1640 1780 1690
0.40 1500 1400 1665 1565 1715 1620
.050 1410 1305 1595 1480 1655 1545
W60HC
0.00 1485 1490 1985 1890 2075 2005 2165 2030
0.10 1430 1365 1920 1830 2015 1950 2085 1985
0.15 1400 1305 1890 1800 1985 1920 2050 1960
0.20 1360 1250 1855 1765 1955 1885 2015 1935
0.25 1820 1730 1920 1855 1985 1910
0.30 1785 1690 1890 1820 1955 1880
0.40 1715 1605 1825 1750 1900 1820
.050 1645 1515 1755 1675 1855 1750
1
E.S.P. is the total combined external static pressure of both the supply and return ducts or grills.
2
This is the speed set at the factory.
