13-3
MODEL DESCRIPTION- 495B SE
®
3
1
2
1
34
2
SPECIFICATIONS
Horizontal Reach: 32’
Vertical Reach: 37’ -7”
Maximum Lift Capacity: 28,720 lbs
Swing Torque: 44,000 ft-lbs
8’-8” with optional 1,300 lb counterweight
8’-10” with optional 3,000 counterweight
Total Operating Weight: 27,000 lbs without attachment or cw
2. Overall Length: 40’ 7” with 32’ boom extended
3. Overall Width: 8’-5”
4. Tail Swing: 8’-6” without counterweight
1. Overall Height: 11’-4”
495B Stationary Electric (SE)
3. Bottom Plate: 49” diameter
1. Height: 33”
2. Top Plate: 43.25” diameter
Bottom Holes: (36) - 1-3/8” dia holes eq spaced on a 42” dia circle
495B Stationary Electric (SE) - Pedestal
07/26/2018
Updated
