13-4
®
MODEL DESCRIPTION- 595B SE
1
34
2
3
1
2
SPECIFICATIONS
Total Operating Weight: 29,000 lbs without attachment or cw
3. Overall Width: 8’-5”
8’-7” with optional 3,000 counterweight
2. Overall Length: 40’ 7” with 30’ boom extended
1. Overall Height: 11’-4”
4. Tail Swing: 8’-6” without counterweight
Maximum Lift Capacity: 38,820 lbs
Horizontal Reach: 32’
595B Stationary Electric (SE)
Swing Torque: 55,000 ft-lbs
Vertical Reach: 37’ -7”
595B Stationary Electric (SE) - Pedestal
1. Height: 33”
3. Bottom Plate: 52” diameter
2. Top Plate: 49” diameter
Bottom Holes: (36) - 1-3/8” dia holes eq spaced on a 46” dia circle
07/26/2018
Updated
