SH 18 Frame - PARTS LIST
Rotor Kit .......................See Table on Page 31
(◊) 13, 16, 30
Stator Kit ......................See Table on Page 31 (≈) 1, 14, 20, 29, 31, 32, 34, 38
Seal Kit .........................See Table on Page 30 (+) 4A, 4B, 5, 7, 9A, 9B, 9C, 33
Bearing Kit .....................................p/n 138579 (●) 3, 17, 18, 19
Hardware Kit ..................................p/n 138615 (♦) 2, 8, 8A, 20, 39
Volute Kit ......................See Table on Page 26 (■) 10, 11, 31, 32
Seal Plate Kit ................See Table on Page 26 (‡) 14, 26, 31, 32
Bearing Bracket Kit .......................p/n 138610 (◘) 28, 31, 32
Terminal Block Kit .........................p/n 138593 (§) 24, 25, 33, 37, 39
Moisture Sensor Kit .......................p/n 138613 (−) 27, 35, 36, 40
Impeller Attachment Kit ................p/n 138614 (○) 8, 8A
Leg Kit ..........................See Table on Page 29
ITEM QTY PART NO. DESCRIPTION MATERIAL
1 1 133023 ≈ Housing, Motor Class 30 CI
2 127223 ♦ Screw, SHCS, M12 x 1.75 x 25 18-8 SS
3 1 0033607 ● Ring, Snap, Tru-Arc Steel
4A 1 133029 + Seal, Mechanical Type 21, 1.5”, C/CE/B
4B 1 133029SD + Seal, Mechanical Type 21, 1.5”, SC/SC/B
5 2 133048 + Ring, Retaining, EXT, 5100 420 SS
6 1 See Table Single Sale Impeller Ductile Iron
7 1 Q21-20-J8 + Key, ¼ x ¼ x 1½” 303 SS
8 1 136284 ♦ ○ Screw, SHCS, M12 x 1.75 x 30 18-8 SS
8A 1 136233 ♦ ○ Washer, Imp, .50 x 1.50 18-8 SS
9 See Table + O-Ring
9A 2 125857-163 + O-Ring, M3 x 163, 70 Duro Buna-N
10 See Table ■ Wear Ring (Volute) Bronze
11 See Table ■ Volute Cast Iron
12 48oz 029034 Seal Chamber Oil Fill Oil
13 1 121305 ◊ Ring, Snap, Tru-Arc Steel
14 2 014270-SS ≈ ‡ Plug, Pipe, 0.375-18NPT, SS
16 1 0038377 ◊ Ring, Snap, Tru-Arc Steel
17 1 0016456 ● Bearing, Ball, 3308
18 1 0038378 ● Bearing, Ball, 6305
19 1 133041 ● Washer, Springer, Wavy, 72mm Steel
20 1 0058556 ≈ ♦ Screw, Set SS
21 1 127264 No Resale Nameplate, Main 300 Stainless Steel
22 4 001628 No Resale Rivet, Nameplate Stainless Steel
23 1 133032 Single Sale Handle, Lifting 304 Stainless Steel
24 1 133031 § Block, Term, 17 pin, 180, Quick Valox/BR
25 1 133049 § Ring, Retaining Steel
26 1 See Chart ‡ Plate, Seal Class 30 CI
27 2 127234C − Wire, Jumper, Orange, 18”, Bar/Bar
28 1 133027 ◘ Bracket, Bearing Class 30 CI
29 1 133021 ≈ Stator
30 1 133022 ◊ Assy, Rotor/Shaft
31 5 125502 ≈ ■‡◘ Paint, Epoxy, Part “A”, Blue
32 5 125503 ≈ ■‡◘ Paint, Epoxy, Part “B”, VF-525
33 1 2-31003-234 + § O-Ring, 2-234, Buna-N, 70 Duro Buna-N
34 1 127270 ≈ Plug, Cap, 3.37”, Tapered PE
35 1 127267 − Resistor, Moisture, Sensor
36 2 125856 − Sensor, Moisture, ¼-18NPT, AMP PP / SS
37 1 127249 § Wire, Jumper, Green, 6”, Bar/O-Ring, 8G
38 1 039462 ≈ Tie, Cable
39 2 125855 ♦ § Screw, SHCS, M5 x 0.8 x 8 Stainless Steel
40 2 134013 − Connector, Wire, Clip
