30
Figure 36
It’s possible to change test parameters relative to only one zone: just select this zone in the
list of Figure 3, then press the button.
Advised values are:
Table 8: advised values
Nozzle zone
25
6
2
Hot runner – heater band zones
60
20
2
6.9 “boost” function
“boost” function can be activated, after the Set Point is reached, with the button .
Confirmation is needed.
Figure 37
