Figure 34: test page
Press button. All the controller zone are switched in “OFF” mode. Referring to Figure
34, the first zone of the list will be switched in “MANUAL” mode and the heating power set to the
value . If after a time of current temperature is increased of at least
, test result is positive. Then the test routine is recursively performed on all the
selected zone.
Figure 35
In the column are described the possible anomalies. At the end of the test routine, all
the zones will be in “OFF” mode.
Parameters “P1%”, “T1” and “Delta T1” can be changed with button.
