The synoptic configuration (background picture and virtual instrument positions) is stored
inside the recipe.
6.11 “recipes” environment
Figure 47: recipes
Press the button to get access to the menu of Figure 47. In the top area is reported
the name of the active recipe and the measure unit. If any setting was modified after the recipe
was saved last time, a warning “Active recipe was modified” is displayed.
6.11.1 Recipe saving
In the menu of Figure 47, the button allows to save the current
settings (zone and common parameters and synoptic configuration) in a new or existing recipe.
