50
Table 10: common parameters, highlighted in grey if read-only even with “Administrator” level of access.
Idx
Parameter
Dec. digits
M.U.
Min
Value
Max
Value
Default
Value
0
Cycle time
(if changed, the new value will be active at the next system
start up)
1
sec
0.5
10.0
2.0
1
% SP end Soft Start - start Auto Tuning
0
%
1
100
25
2
SP1/SP2 selection
0
0=SP1
1=SP2
0
4
Baud Rate
-
38400
38400
38400
5
Synchronous heating tolerance
0
°C
0=off
100
10
6
Band outside of that fuoc value is idx 7
(if the ramp is active)
1
°C
0
9999
30.0
7
Fuoc value outside of band (referring to parameter idx=6)
1
-
0.1
10.0
1.0
8
K_TAU for Auto Tuning calculation
1
-
0.1
100.0
20.0
9
K_FPB for Auto Tuning calculation
1
-
0.1
100.0
4.0
10
Cpb, corrective factor for proportional band
1
-
0.1
100.0
1.5
11
Drying time
0
sec
0
999
900
12
Drying voltage
0
Volt
60
190
160
13
Proportional Band under Auto Tuning temperature
1
°C
0
199.9
1.0
14
Integral time under Auto Tuning temperature
0
sec
0
999
0
15
Derivative time under Auto Tuning temperature
0
sec
0
999
0
16
Temperature threshold to abort Soft Start
0
°C
0
999
80
17
Digital filter for displayed temperature
1
°C
0.0
10.0
2.0
18
OUTPUT 1 (enabling signal) logical level
-
-
0:open=OK
1:close=OK
1
19
OUTPUT 2 (alarm signal) logical level
0:open=Fail
2:open=Fail
1:close=Fail
3:close=Fail
3
20
WAIT Output enabled (OUTPUT 3)
0: not active
1:active
1
21
Logical level OUTPUT 4 (used for fans)
22
INPUT 1 (switch to SP2) logical level
0:open=SP2
1:close=SP2
1
23
INPUT 2 (switch to “OFF” all the zones) logical level
0:open=OFF
1:close=OFF
1
24
Logical level INPUT 3 (not used)
25
Hold band for wait after end of Auto Tuning
0
°C
0
100
15
26
Validate band of temperature around SP (LEAKAGE ALARM)
1
°C
0
999.9
5.0
27
Delay after Set Point is reached for power calculation
(LEAKAGE ALARM)
0
sec
30
7200
900
28
Time for average power calculation (LEAKAGE ALARM)
0
sec
30
7200
300
29
Relative power % increasing to get the LEAKAGE ALARM
0
%
0
100
50
30
Digital output delay
0
min
0
1000
1
31
Set Point change band for LEAKAGE ALARM power
recalculation
0
°C
0
100
15
