Barnstead F62730 - Replacement Parts List; Common Furnace Replacement Parts and Numbers

44
Listed below are the common replacement parts for all models of the F62700 furnace.
PART PART NO.
Temperature Control (Single Set Point Models) CN71X76
Temperature Control (8 Segment Programmable Models) CN71X77
Muffle Heating Element 100V EL1075X3A
Muffle Heating Element 120V EL1075X1A
Muffle Heating Element 220-240V EL1075X2A
Solid State Relay RYX34
Mechanical Relay 120V, 100V RYX56
Mechanical Relay 220-240V RYX57
On/Off Switch 120V SWX143
On/Off Switch 220-240V SWX144
Fan 120V, 100V FAX29
Fan 220-240V FAX7
Door Switch SW1172X1
Thermocouple TC517X1A
Door Insulation JC517X1
Hearth Plate (2 required) PH421X1
Pilot light, 100V & 120V PLX76
Pilot light, 220-240V PLX82
Door Assembly, with Insulation DR1075X1A
Fuses, Type Non-Time lag, 250 Volt, 10 Amp (F62730 Models) FZX30
Fuses, Type Non-Time lag, 250 Volt, 20 Amp (F62734, F62735 Models) FZX29
Replacement Parts
Warning
Replace fuses with the same type and rating.
