Bartell BC120 - Engine;Clutch;Hoist Hook Assemblies (Bc90;Bc436)

CREATED: 07/04
REVISED: 07/14
375 ANNAGEM BLVD., MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
200 COMMERCE DRIVE, FREEHOLD, NEW JERSEY, USA, 07728, 732-566-5400 FAX 732-566-5444
WALK BEHIND POWER TROWEL INSTRUCTION MANUAL
23
375 ANNAGEM BLVD., MISSISSAUGA, ONTARIO, CANADA L5T 3A7, 905-364-4200 FAX 905-364-4201
CREATED: 07/04
REVISED: 05/10
ENGINE/CLUTCH/HOIST HOOK ASSEMBLIES (BC90/BC436)
110
49
50
86
87
88
89
90
82
45
91
92
93
94
95
96
98
97
21
Item Part Number Description Qty. Item Part Number Description Qty.
45 50117
SHSS, 5/16”-18 x 1/2” LG, Cup PT
1
91
21022 Clutch Drum - GX160 1
49
10783
HHCS, 5/16”-24 x 1 3/8” LG - GX160
1 21046 Clutch Drum - GX270 1
981135
HHCS, 7/17”-20 x 1/4” LG - GX270
1
92
11020 Bearing, 6006-2RS - GX160 1
50
11614 Lockwasher, M8 - GX160 1 11044 Bearing - GX270 1
13491 Lockwasher, 7/16” - GX270 1
93
11021 Spindle - GX160 1
82
10287 Belt Guard - GX160 1 11045 Spindle - GX270 1
10331 Belt Guard - GX270 1
94
11030 Belt, A25 - GX160 1
10104 Spacer - GX270 2 11047 Belt, B28 - GX270 1
86
10777
Flat washer, 45mm x 10mm x 2.85mm
1 95 30041 FHSCS, 5/16-24 x 3/4” 4
11355
Plate Washer, 50mm x 10mm x 4mm
1
96
10201 Hoist Hook - GX160 1
87
11026 Clutch Cover, sm - GX160 1 10300 Hoist Hook - GX270 1
11015 Faceplate - GX270 1
97
21333 GX160 Honda 1
88
11025 Weight - GX160 4 21334 GX270 Honda 1
89
15759 Clutch Spring - GX160 1 98 10786 Hex lock nut, anged, M8-1.25 4
10759 Spring - GX270 1
110
21006
Clutch Assm. Complete, 3/4” shaft - GX160
1
11014 Weight - GX270 4 21029
Clutch Assm. Complete, 1” shaft - GX270
1
90
11023 Bushing, copper - GX160 1 111 11254 Spacer (Hoist Hook) - GX160 1
11012 Bushing - GX270 1
