4. OPTIONS SECTION
Delay - This key is used to delay the start of a firing.
Example: Program a one hour delay to the start of a firing.
Remember: the temperature must be flashing before beginning to program.
Step Press Display Comment
1 Delay Alternately flashing:
dELA and 00.00
The controller is ready to accept the delay time of 1 hour.
2
1, 0, 0
01.00
Displays the selected time. Numbers to left of decimal point are
hours, to the right of decimal point are minutes. If you type a
wrong number, press zero 4 times, then type the correct number.
3
ENTER
CPL flashes then the current
temperature
CPL flashes several times indicating the 1 hour delay has been
accepted. The current temperature then flashes in the display.
Alarm - This key is used to set the high or low temperature alarm. The alarm may be set before or during a firing.
When the alarm temperature is reached, a buzzer will sound.
Example: Before the start of a firing, set the alarm temperature to go off at 200°F.
Remember: the temperature must be flashing before beginning to program.
Step Press Display Comment
1
Alarm
Alternately flashing:
ALAr and #
The word ALAr and the last entered alarm temperature will
alternately flash on the display. The controller is ready to accept the
alarm temperature. If no alarm is entered within 10 seconds, the
display will flash CPL and then the current temperature.
2 2, 0, 0 0200
Displays the selected temperature of 200°. If you type a wrong
number, press zero 4 times, then type the correct number.
3 ENTER CPL flashes then the
current temperature
CPL flashes several times indicating the alarm temperature has been
accepted. The current temperature then flashes in the display.
Other – There are nine “Other” options. Pressing “Other” will continue to cycle through the options
available, Rset (reset), PrHt (Preheat), Id (identification), 16-S (16 segment), CnoS (Cone Offset) ,
CHG° (Change °F to °C), ErCd (Error Codes), tCoS ( thermocouple offset ), bd t (board
temperature), and LAG (Lag setting).
NOTE: PrHt (Preheat) will not appear in this menu unless a CONE FIRE mode has been selected. 16-S will not appear
unless User 5 is the selected program.
TO EXIT this menu without selecting any option, cycle through by pressing “Other” until CHG° appears, then
press ENTER twice.
rSEt (RESET) - press “OTHER” until rSEt is displayed, then press “ENTER”. CPL will be displayed indicating
that the T/C offsets have been set to zero, the LAG to 13, and the error codes are turned ON.
PrHt (Preheat) - Preheat is used with the CONE FIRE mode only. When Preheat is in used, the temperature ramps
up at 60°F/hour to 200°F and then holds at 200° for the amount of time programmed. So if you start at a room
temperature of 70°F, then it will take just over 2 hours to reach 200°F at which time the hold time will start. Preheat
is automatically set to zero during cone fire programming and at the end of each firing. If a preheat stage is desired, it
must be reprogrammed for each firing.
