Baruffaldi CE 13 - Structure of the Gearbox

USE AND MAINTENANCE MANUAL
2-Speed Gearboxes Series CE
M.CE.GEN.ENG.DOCX
Issued
2018
Rev.03
Page 6 / 59
Flange Output Shaft Output
Flange Output - Gearbox type CE 20 - Shaft Output
1 STRUCTURE OF THE GEARBOX
02
04
01
04
02
01
03
03
Fixing holes for
"feet mounting"
Actuator Motor
Centering diameter for
"flange mounting"
Fixing holes for
"flange mounting"
Centering diameter
for "flange mounting"
09
Motor Fixing Holes
05
Motor Centering
Diameter
03
Actuator motor
01 Housing
02 Actuator
03 Motor flange (*)
04 Output flange (*)
05 Output shaft (*)
09 Pinion (*)
(*) according to the ordering code
05
Fixing holes for
"flange mounting "
