USE AND MAINTENANCE MANUAL
2-Speed Gearboxes Series CE
M.CE.GEN.ENG.DOCX
Issued
2018
Rev.03
Page 36 / 59
OPP
B5 Horizontal
OPS
B5 Horizontal turned
VFB
V1 Vertical downward
VFA
V3 Vertical upward
4.4 GEARBOX ASSEMBLING DESIGNATION
The different assembling positions on the machine are identified with a specific code, ase described
below
4.5 LUBRICATION EXAMPLES
In the following pages, some examples of lubrication layouts are shown for some gearbox sizes.
Changing the connection points, these examples can be used as a reference for all gearbox sizes.
