USE AND MAINTENANCE MANUAL

2-Speed Gearboxes Series CE

M.CE.GEN.ENG.DOCX

Issued

2018

Rev.03

Page 44 / 59

4.7 ASSEMBLING POSITIONS & LUBRICATION - CE 12

In position B and B1, injectors are fitted for lubrication oil.

Do not remove or turn, seizing danger!
