FA-(B)W – EN 22
CHECK WEEKLY
1. Check the chain tension.
Screw fill plug of the chain guard loose.
With a small hook you can lift the chain and check the tolerance of the chain.
The right tolerance is 0 to ½ cm.
In case the tolerance is higher, screw the tension bolt on the other side of the chain guard
till the correct tolerance is reached (see page 23).
2. Make sure all bolts and nuts, especially those of the hook tines or spikes, are tightened well
with a fitting ring tool (page 21).
3. Tension of the chain - Check (page 23)
4. PTO shaft - 2 grease points PTO shaft tube (page 10)
- 2 grease points cross PTO shaft (page 10)
5. Bearing rotor shaft - 1 grease point (grease slowly) (page 24)
6. Bearings 9 depth wheels - 4 grease points (grease slowly) (page 24)
7. Depth wheels (9 pieces) - Check tire pressure (1,6 bar)
8. Ridging discs - 8 grease points (grease slowly) (page 24)
9. Hook tines - Check for wear
10. PTO shaft + bearing top shaft - 4 grease points PTO shaft top shaft (page 44)
(only FA 310-380BW) - 2 grease points bearing top shaft
PROBLEMS AND SOLUTIONS
PROBLEM
CAUSE
SOLUTION
Soil is pushed forward
Too deep working depth
Too much spring pressure
on full width plate
- Lower the depth wheels with hydr.
cylinder to decrease the working depth
- Reduce vertical spring pressure on full
width plate
Crumbling of the soil is
not right
Driving speed
- Increase or decrease driving speed
Machine is requiring too
much power
Too much soil in front of
the ridging discs
Too much soil is pressed
against the full width plate
Too much spring pressure
on full width plate
- Set the ridging discs wider or adjust
the angle of the ridging discs
- Lower the depth wheels with hydr.
cylinder to decrease the working depth
- Reduce vertical spring pressure on full
width plate
