FA-(B)W – EN 47
14. HYDRAULIC ADJUSTMENT RIDGING HOOD
The machine is equipped with a hydraulic adjustable ridging hood.
The hydraulic pressure can be set from 30 bar up to 40 bar, depending on the speed and the
working width of the machine.
When the ridging hood is working on working depth the pressure can be controlled.
In case of more than 50 bar hydraulic pressure, the system will block.
