Basic American ZENITH Series - Page 37

GF Health Products, Inc. - www.grahamfield.com Zenith Series Service Manual 999-0831-190C DEC. 2013
37
ZENITH SERIES
SERVICE/REPLACEMENT PART DIAGRAM -
CAPPING ON HEAD, KNEE, AND FOOT DECKS
CAPS OR PLUGS ARE NOT COVERED UNDER WARRANTY
(PACKS OF 12 CAN BE ORDERED IN THE EVENT YOU DAMAGE OR LOSE
ANY CAPS/PLUGS ON THE BED - SEE BOTTOM OF PAGE 31 FOR ORDER NUMBERS)
CAPPING ON ARMS & LEGS
2X 100-4700-018
Rectangular End Caps
4X 100-4715-011
Round End Caps
2X 100-4700-018
End Caps
2X 100-4700-021
Rectangular End Caps
12x 100-4200-004
Square Caps in
ends of all Decks
4x 100-4762-002
5/8” Round Plugs (Caps)
Sides of Foot Deck Only
