DGC-2020ES Specifications
Specifications
DGC-2020ES electrical and physical characteristics are listed in the following paragraphs.
Control Power
Nominal ............................................ 12 or 24 Vdc
Range ............................................... 6 to 32 Vdc
Terminals.......................................... 18 (+), 17 (–), 16 (chassis ground)
Power Consumption
Sleep Mode ...................................... 4.5 W - LCD heater off, all relays de-energized
Normal Operational Mode ................ 6.5 W - Run mode, LCD heater off, 3 relays energized
Maximum Operational Mode ............ 14 W - Run mode, LCD heater on, 7 relays energized
Battery Ride Through
Starting at 10 Vdc, withstands cranking ride-through down to 0 Vdc for 50 ms
Current Sensing
Burden .............................................. 1 VA
Terminals.......................................... 38, 37 (A-phase)
36, 35 (B-phase)
34, 33 (C-phase)
1 Aac Current Sensing
Continuous Rating ............................ 0.02 to 1.0 Aac
1 Second Rating ............................... 5 Aac
0.050 Second Rating ........................ 10 Aac
5 Aac Current Sensing
Continuous Rating ............................ 0.1 to 5.0 Aac
1 Second Rating ............................... 25 Aac
0.050 Second Rating ........................ 50 Aac
Voltage Sensing
Range ............................................... 12 to 576 V rms, line-to-line
Frequency ........................................ 50/60 Hz
Frequency Range ............................. 10 to 72 Hz
Burden .............................................. 1 VA
1 Second Rating ............................... 720 V rms
Generator Sensing
Configuration .................................... Line-to-line or line-to-neutral
Generator Sensing Terminals .......... 45 (A-phase)
43 (B-phase)
41 (C-phase)
40 (Neutral)
