Basler DGC-2020ES Instruction Manual

28 9469200994 Rev —
Specifications DGC-2020ES
Shock
Withstands 15 G in three perpendicular planes.
Vibration
Tested in three mutually perpendicular planes for 8 hours over the following ranges:
3 to 25 Hz at 0.063 inches (1.6 mm), peak amplitude
25 to 2,000 Hz at 5G
Radio Interference
Type tested using a 5 W, hand-held transceiver operating at random frequencies centered around 144
and 440 MHz with the antenna located within 150 mm (6”) of the device in both vertical and horizontal
planes.
HALT (Highly Accelerated Life Testing)
HALT is used by Basler Electric to prove that our products will provide the user with many years of
reliable service. HALT subjects the device to extremes in temperature, shock, and vibration to simulate
years of operation, but in a much shorter period span. HALT allows Basler Electric to evaluate all possible
design elements that will add to the life of this device. As an example of some of the extreme testing
conditions, the DGC-2020ES was subjected to temperature tests (tested over a temperature range of
–100°C to +130°C),
vibration tests (of 5 to 50 G at +20°C), and temperature/vibration tests (tested at 50 G
over a temperature range of –95°C to +125°C). Combined temperature and vibration testing at these
extremes proves that the DGC-2020ES is expected to provide long-term operation in a rugged
environment. Note that the vibration and temperature extremes listed in this paragraph are specific to
HALT and do not reflect recommended operation levels.
Ignition System
Tested in close proximity to an unshielded, unsuppressed Altronic DISN 800 Ignition System.
Environment
Operating Temperature .................... –40 to +158°F (–40 to +70°C)
Storage Temperature ....................... –40 to +185°F (–40 to +85°C)
Humidity ........................................... IEC 68-2-38
Salt Spray ......................................... IEC 68-2-52
Ingress Protection ............................ IEC IP56 for front panel
UL Approval
The DGC-2020ES is a Recognized Component applicable to the Canadian and US safety standards and
requirements by UL. The product is covered under UL File (E97035 FTPM2/FTPM8) and evaluated to the
following standards through UL:
• UL6200
• CSA C22.2 No. 14
CSA Certification
The DGC-2020ES is Certificated under CSA report 1042505 (LR23131-138S) and evaluated to the
following standards through CSA:
• CSA C22.2 No. 0
• CSA C22.2 No. 14
