Basler DGC-2020ES User Manual

4-2 9469200995
Communication DGC-2020ES
ECU Parameter Metric Units English Units Update Rate
∗
SPN
Aftertreatment 1 Diesel Particulate Filter
Intermediate Temperature (DOC Outlet
Temperature)
°C
°F
500 ms
3250
Aftertreatment 1 Diesel Particulate Filter
Outlet Temperature
°C
°F
500 ms
3246
Air Filter Differential Pressure
kPa
psi
500 ms
107
Air Inlet Temperature
kPa
°F
1 s
172
Alarm Reset Feedback
Binary (0 or 1)
1 s
2815
Ambient Air Temperature
°C
°F
1 s
171
Auxiliary Pressure 1
kPa
psi
On Request
1387
Auxiliary Pressure 2
kPa
psi
On Request
1388
Barometric Pressure
kPa
psi
1 s
108
Battery Charger 1 State
0 = Idle (not Connected to Battery)
1 = Charging
2 = Maintaining Battery Charge
3–12 = Reserved
13 = Battery Failure
14 = Charger Failure
15 = Not Available
1 s
4990
Battery Charger 1 AC Line State
0 = Disconnected
1 = Connected
2 = Error
3 = N/A
1 s
4991
Battery Charger 1 Output Voltage
Vdc
Vdc
1 s
4992
Battery Charger 1 Output Current
Adc
Adc
1 s
4993
Battery Charger 2 State
0 = Idle (not Connected to Battery)
1 = Charging
2 = Maintaining Battery Charge
3–12 = Reserved
13 = Battery Failure
14 = Charger Failure
15 = Not Available
1 s
4994
Battery Charger 2 AC Line State
0 = Disconnected
1 = Connected
2 = Error
3 = N/A
1 s
4995
Battery Charger 2 Output Voltage
Vdc
Vdc
1 s
4996
Battery Charger 2 Output Current
Adc
Adc
1 s
4997
Battery 1 Temperature
°C
°F
1 s
1800
Battery 2 Temperature
°C
°F
1 s
1801
Battery Voltage
Vdc
Vdc
1 s
168
Boost Pressure
kPa
psi
500 ms
102
Charge Air Temperature
°C
°F
1 s
2629
Coolant Level
%
%
500 ms
111
Coolant Pressure
kPa
psi
500 ms
109
DEF Inducement Level - Level of
Inducement Not to Run the Engine
%
%
1 s
5246
DEF Severity Level - Severity of Tank
Low Level
%
%
1 s
5245
DEF Tank 1 Level
%
%
1 s
1761
