Page #101 background imageLoading...
Page #101 background image
9469200995 13-1
DGC-2020ES BESTlogicPlus
13 • BESTlogicPlus
BESTlogicPlus Programmable Logic is a programming method used for managing the input, output,
protection, control, monitoring, and reporting capabilities of Basler Electric's DGC-2020ES Digital Genset
Controller. Each DGC-2020ES has multiple, self-contained logic blocks that have all of the inputs and
outputs of its discrete component counterpart. Each independent logic block interacts with control inputs
and hardware outputs based on logic variables defined in equation form with BESTlogicPlus.
BESTlogicPlus equations entered and saved in the DGC-2020ES system's nonvolatile memory integrate
(electronically wire) the selected or enabled protection and control blocks with control inputs and
hardware outputs. A group of logic equations defining the logic of the DGC-2020ES is called a logic
scheme.
One default active logic scheme is preloaded into the DGC-2020ES. This scheme is configured for a
typical protection and control application and virtually eliminates the need for "start-from-scratch"
programming. BESTCOMSPlus
®
can be used to open a logic scheme that was previously saved as a file
and upload it to the DGC-2020ES. The default logic scheme can also be customized to suit your
application. Detailed information about logic schemes is provided later in this section.
BESTlogicPlus is not used to define the operating settings (modes, pickup thresholds, and time delays) of
the individual protection and control functions. Operating settings and logic settings are interdependent
but separately programmed functions. Changing logic settings is similar to rewiring a panel and is
separate and distinct from making the operating settings that control the pickup thresholds and time
delays of a DGC-2020ES. Detailed information about operating settings is provided in the
BESTCOMSPlus chapter.
Caution
This product contains one or more nonvolatile memory devices.
Nonvolatile memory is used to store information (such as settings) that
needs to be preserved when the product is power-cycled or otherwise
restarted. Established nonvolatile memory technologies have a
physical limit on the number of times they can be erased and written.
In this product, the limit is 100,000 erase/write cycles. During product
application, consideration should be given to communications, logic,
and other factors that may cause frequent/repeated writes of settings
or other information that is retained by the product. Applications that
result in such frequent/repeated writes may reduce the useable
product life and result in loss of information and/or product
inoperability.
Overview of BESTlogicPlus
Use BESTCOMSPlus to change BESTlogicPlus settings. Use the Settings Explorer to open the
BESTlogicPlus Programmable Logic tree branch as shown in Figure 13-1.
The BESTlogicPlus Programmable Logic screen contains a logic library for opening and saving logic files,
tools for creating and editing logic documents, and protection settings.
