Basler DGC-2020ES User Manual

9469200995 5-3
DGC-2020ES Device Configuration
Rated Volts (V L-L)
This setting accepts values from 1 to 99,999, in increments of 1.
Rated Power Factor (PF)
This setting accepts values from -1 to 1, in increments of 0.001.
Genset kW Rating
This setting accepts values from 5 to 9,999, in increments of 1.
Rated Engine RPM
This setting accepts values from 25 to 3,600, in increments of 1.
Calculated Rated Data
Rated Secondary Volts, Rated Phase Amps, Rated Secondary Phase Amps, Rated kVA, and Rated kvar
are calculated automatically. The equations used for these calculations are listed below.








=
VoltsPrimaryPT Gen
VoltsSecondaryPTGen
VoltsRatedVolts
SecondaryRated
3VoltsLLRated
kVARated
machine)phase(3AmpsPhaseRated
−
=−
VoltsLLRated
kVA
Rated
machine)phase(1AmpsPhaseRated
−
=−








=
AmpsPrimaryCT
Amps
SecondaryCT
Amps
PhaseRated
AmpsPhaseSecondary
Rated
PFRated
kW
Rated
kVARated
=
2
PFRated1kVARatedkvarRated −=
Frequency
The frequency settings allow selection of the rated frequency of the generator and an alternate frequency.
Rated Frequency of the Unit
Rated frequency settings consist of 50 and 60 Hz.
Alternate Frequency
This setting accepts values from 10 to 450, in increments of 0.01.
Battery Volts
The nominal voltage of the starter battery is used by the DGC-2020ES to detect and annunciate battery
overvoltage and low or weak battery voltage. The Battery Volts settings consist of 12 V and 24 V.
Generator Connection
Genset connection types accommodated by the DGC-2020ES include three, three-phase connections
(delta, wye, and grounded delta) and a single-phase configuration (sensing across phases A and B.)
Bus Connection
Bus connection types consist of single- and three-phase. Single-phase bus voltage is sensed across
phases A and B.
