Battery Powered Photoelectric Smoke Alarm BAT
User’s Handbook 33 Status: 07-2008
WARNING: To prevent any risk of an explosion, do not
attempt to charge or tamper with batteries or throw them into the
fire. Observe the safety precautions relating to the charger and
the batteries.
WARNING: To prevent any risk of an explosion, do not
tamper with batteries or throw them into the fire.
IMPORTANT: If the smoke alarm will not be used for a
prolonged period of time, remove the battery. This will prevent
any damage rising from an old, discharged battery.
WARNING: The acoustic alarm is very loud (85 dB). Do
not carry out function tests in the presence of children or pets.
5 Technical data
Appliance: BT-166
Mark of approval: VdS approved
Type of protection: IP 20
Voltage: 9 VDC carbon zinc
(IEC 6F22)/alkaline battery
(IEC 6LR61) or MN1604
Max. current: < 20 mA (alarm)
Ambient temperature: 0°C – 40°C
Relative humidity: 10%- 90%
Alarm volume: 85 dB (at 3 m distance)
Battery life: min. 1 year
