Battery Powered Photoelectric Smoke Alarm BAT
User’s Handbook 41 Status: 07-2008
Step Action Description
Pos. Description Function
6 Mounting lug Holds the housing
in place
7 Mounting plate To be fastened to a
ceiling
8 Mounting holes To secure the
mounting plate to
the ceiling
2 Install
battery
See section 7.3, steps 3 and 4
8
7
6
