Battery Powered Photoelectric Smoke Alarm BAT
User’s Handbook 43 Status: 07-2008
Step Action Description
IMPORTANT: The battery must be
connected to the battery clip with the
correct polarity.
Pos Description Function
5 Battery Power supply
3 Connect new
battery
9 Battery clip Battery terminal
Place the connected battery in the
battery compartment
Pos Description Function
4 Install battery
10 Battery
compartment
Location for
battery
5
9
10
