Bauer Compressors MAXI VERTICUS - Page 48

MVT26
October 2003 Section 3 Page 47
Item Qty Part No. Description Notes
◊ 1 077387 Interfilter Assembly
1 † … Filter Housing Available only with 077387
2 † … Filter Head Available only with 077387
3 1 13937 Collar, Threaded Knurled
4 1 N3556 O-ring
5 1 76613 Tube and Baffle
6 1 N1316 Gasket, Cooper
7 1 N20215 Male Fitting
N.S. 1 VAL-0169 Safety Valve
Figure 3.1-31 2nd Stage Interfilter Assembly
2
4
5
1
3
6
7
