Page 11For technical questions, please call 1-888-866-5797.Item 59098
SAFETYOPERATIONMAINTENANCE SETUP
Loading the Tool
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL DISCHARGE, BEFORE LOADING:
• Wear ANSI-approved safety goggles with side shields.
Other people in the work area must also wear ANSI-approved impact safety goggles with side shields.
• Release the Trigger.
• Disconnect the Battery Pack from the tool.
• Attempt to discharge the Tool into a piece of scrap wood to ensure that
it is disconnected and is incapable of driving any fasteners.
Note: PREVENT JAMS! Empty magazine
before loading staples of different length.
1. Depress the Latch and slide back
the Magazine Cover.
Latch
2. Turn tool over and place staples into the
track of the Magazine Channel.
3. Staples should be placed upside down
in magazine with crown closest to the
body of the tool. See Figure A.
4. Gently slide the Magazine Cover back into
place. Magazine Cover should re-engage with
the Latch. CAUTION! Do not pinch your hand.
Latch
Sliding Magazine
Fixed Magazine
Staples
(not included)
Figure A: Loading Stapler
