Part Description Qty
1 Foot 4
3 Motor Position Lock 1
4 Washer 2
6 Head Cap Screw 4
9 Cap Screw 1
10 Bed 1
12 Phillip Head Screw 3
14 Cap Screw 4
15 Washer 8
16 Storage Bracket 2
17 Cap Screw 4
18 Spring Washer 4
19 Headstock 1
20 Spindle Speed Sensor 1
21 Indexer/Spindle Lock 1
24 Headstock Handwheel 1
25 Locking Nut 1
27 Belt Access Door 1
28 Cap Screw 2
29 Set Screw 2
30 Bearing 1
31 Ring 2
32 Bearing 1
33 Spindle 1
34 Cap Screw 2
35 FacePlate 1
36 Spur Center 1
37 Live Center 1
38 Quill 1
39 Tailstock 1
40 Quill Lock Handle 1
41 Pin 1
42 Lead Screw 1
43 Tailstock Handwheel 1
44 Handwheel Axle 1
45 Washer 1
46 Handwheel Handle 1
47 Set Screw 1
48 Tailstock Locking Lever 1
Part Description Qty
50 Tailstock Clamp Bolt 1
51 Tailstock Clamp 2
52 Lock Nut 2
53 C-Ring 1
57 C-Ring 2
59 Tool Rest Lock Handle 1
60 Tool Rest Clamp Bolt 1
71 Phillips Screw 2
75 Digital Readout 1
77 Wrench 2
78 Hex Wrench 3mm 1
79 Hex Wrench 4mm 1
80 Hex Wrench 5mm 1
81 Hex Wrench 12mm 1
82 Handle Sleeve 1
84 Headstock Cover 1
86 Power Cord 1
200 Control Box Assembly 1
201 Motor 1
202 Motor Tension Lever 1
203 Motor Pulley 1
204 Spindle Pulley 1
205 Belt 1
207 Tool Rest Lock Lever 1
208 Tool Rest Base 1
209 8" Tool Rest 1
210 Control Box Bracket 2 1
211 Control Box Bracket 1 1
212 Washer 6
213 Screw 6
214 Screw 4
215 Carbon Brush 2
216 Carbon Brush Cap 2
220 Knockout Rod 1
221 Screw 3
222 Pointer 1
223 Belt Pulley Hatch 1
224 Screw 1
225 Magnet 1
Parts List and Diagram
