DESCRIPTION OF THE CONTROLS
HOB GAS BURNER KNOB (A)
By rotating the knob in an anticlockwise direction, the
following symbols appear:
0
= Closed position
= “Full on” position
= “Reduced rate or Low” position
OVEN THERMOSTAT KNOB (B)
By turning the oven knob clockwise we will nd the
different oven temperature values (from 50°C to
Max).
OVEN FUNCTION SELECTOR KNOB (C)
By turning the knob to the right or to the left we will nd
the following symbols:
0
= Oven off
= Oven light on, which stays on for all functions
= Defrost
= Top and bottom heating elements
= Top and bottom heating elements and fan
= Bottom heating element and fan
= Fan forced heating element and fan
= Grill heating element
= Grill heating element and fan
ENERGY REGULATOR KNOB (E-F)
By turning the knob to the right we nd the following
symbols:
0
= heating elements off
from 1 to 12
= minimum and maximum power for single
cooking zone
from 12 to 0
= maximum power for double cooking zone
OVEN FAN BUTTON
RED WARNING LIGHT
When lit it indicates that the electric grill or one of the
oven electric components is on.
YELLOW WARNING LIGHT
When lit it indicates that either the electric oven or
electric grill is working. While the oven is being used
the light will switch off when the set temperature is
reached. During baking it is normal for the yellow light
to switch on and off several times as the oven tempe-
rature is controlled.
DESCRIPTION OF THE APPLIANCE
A
