CONTROL PANEL
7
1 Power / On L i ght: Comes on when the ON / OFF Button is pressed down.
2 Rinse Aid Warning Light: Comes on when Rinse Aid needs to be refilled.
3 Salt Warning Light: Comes on when the softener needs to be refilled.
4 ON / OFF Button: Turns the power supply ON / OFF.
5 Rapid Button: Only used w i th Cycle ‘ ’
6 Plus Button: Only used with Cycle ‘ ’
7 Door Handle: Pu ll it to open the door.
8 Washing Program Selector: Turn the knob clockwise to select wash cycles.
DISHWASHER FEATURES
(ADJUSTABLE)
8 CUTLERY BASKET
4 WATER SOFTENE
R
1 ADJUSTABLE UPPER BASKET 5 MAIN FILTER
9 COARSE FILTER
2 SPRAY ARMS 6 DETERGENT DISPENSER
10 RINSE AID DISPENSER
3 LOWER BASKET 7 CUP & GLASS SHELF
11 DRAIN PIPE CONNECTOR
12 INLET PIPE CONNECTOR
4
1 4 5 6 2 3
8
