Positioning
The adjacent furniture must be able to withstand a
minimum temperature rise of 85°C above the ambient
temperature of the room it is located in, during
periods of use.
This appliance is classified as Class 3 and therefore is to be built into a
kitchen unit (depending on size) or 600 mm worktop that is between
25 mm and 40 mm thick. The following minimum clearance distances
must be observed:-
o 700 mm between the hob surface and the underside of any
horizontal surface above it.
o 50 mm clearance around the sides and front of the appliance.
o 55 mm clearance between the back of the hob surface and the
wall behind it.
o If the hob is positioned so that the right or left hand side of the
appliance will be near to the edge of a kitchen unit. There must
be a gap of at least 150 mm between the side of the hob and the
vertical surface of the kitchen unit.
o IMPORTANT: Underneath the appliance there must be a
partition made of insulating material (e.g. wood). There must be
a gap of at least 50 mm between the underneath of the
appliance and this partition.
o You must make sure that there is a 5mm gap below the
underneath of the worktop at the front edge of the hob.
22
