NE215
6 Technical data
Display 7-segment-LED display
8-digit, red
with minus sign
Digit height 7,6 mm
Power supply As per purchase order
Power consumption 7 VA, 6 W
Encoder power supply 12...26 VDC, max. 80 mA
Optocoupler inputs NPN, PNP
Max. counting frequency 15 Hz, 25 Hz for XB
10 kHz für XP
Data storage > 10 years
Mounting With clamping frame
Dimensions DIN-housing 72 x 72 mm, housing for front panel mounting
Mounting depth 100 mm
Core cross-section max 1,5 mm
2
Housing material Polycarbonate black, UL 94V-0
Weight AC version: approx. 450 g
DC version: approx. 320 g
Ambient temperature 0...+50
o
C
Storage temperature -20...+70
o
C
Relative humidity Max. relative humidity 80%, at 25 °C, not-condensing
General rating EN 61010 part 1
- Protection class II
- Overvoltage protection category II
- Contamination factor 2
Interference immunity EN 50082-2
Emitted interference EN 50081-1
Max. speed Measuring in mm 600 m/min
Max. speed Measuring in cm 6000 m/min
Technical data
