Baumuller BM5300 Series - Type Plate

Design and Operation
Instruction handbook b maXX 5000
Document No.: 5.09021.16
83
of 328
4
4.2.2 Type plate
Examples of the locations where the type plate is affixed are shown in the figure.
Among other things, the type plate also sh
ows the type code of the device.
Figure 35: Affixing of the type plate
