Assembly
22 Basic Supply Unit BUG 622, 623
5.94034.07a Baumüller Nürnberg GmbH
4.3 Attachment
1. Attach the mounting plate to the control cabinet (for sizes, see "Dimensions").
The mounting plate can be used as a mounting and drilling template. The mounting plate of neigh-
boring units must be placed directly next to one another.
2. Push back the plate spring and hang the unit in place.
The unit is then held fast between the mounting backplate and the back wall.
3. To dismount the unit, press the plate spring in direction back wall and lift out upwards.
