Installation
40 Basic Supply Unit BUG 622, 623
5.94034.07a Baumüller Nürnberg GmbH
y Sub-unit terminal X99AB
5.6 Accessories
y Fuses
y EMC
on requirement available:
- EMC Filter
- shielded cables
- shield clamps
Terminal no.. Assignment
1, 2 Ready for use (SELV / PELV)
Relay output,: ready for use supply converter
24 V 0.5 A max.
3, 4 Forewarning (SELV / PELV)
Relay output: Forewarning supply converter
24 V 0.5 A max
5 + Reset with 24-V-Signal (SELV / PELV)
Error message reset input of the supply converter
(potential-free optocoupler input, 8 ... 15 mA)
6
Ground reset (SELV / PELV)
Error message reset reference point of the supply converter
(potential-free optocoupler input)
BUG 622 BUG 623
Semi-conductor fuses
Part no.
80 A / 1000 V
19008531
100 A / 1000 V
19008526
Size according DIN 43620 0 0
mains fuses 35 A medium time-lag only with reduced cross section
