Installation
32
Basic Supply Unit BUG 622, 623
5.94034.07a
Baumüller Nürn
berg GmbH
Shield clamps for grounding
cable diameter
∅
(mm
)
Item no.
2 x 2 - 6 mm
226752
3 - 8 mm
226741
4 - 13,5 mm
226745
10 - 20 mm
226749
larger diameters on request
31
33
