TAM 00621 8
DSD 45-100 05/2007
Three-phase synchronous motor English
2.4 Technical data
Designs (EN 60034-7) IM B5 (IM V1, IM V3 )
Type of protection (EN 60034-5)
Motor housing IP 65
Shaft exit IP 64 (with shaft sealing ring IP 65 as an option)
Fan type of protection IP 54
Terminal box Only up to IP 65
Cooling method (EN 60034-6) Standard: IC 410
Completely enclosed motor design
Self-cooled, no fan
Optional: IC 416 from shaft height 56
Completely enclosed motor
Surface-cooled, with fan
Air flow direction from motor NDE to DE
Electrical connections (see Appendix)
Main connection Standard:
8-pin connector: Shaft height 45 to 56
Terminal box: Shaft height 71 to 100
Optional:
Terminal box: Shaft height 56
8-pin connector: Shaft height 71 to 100
Control connection Resolver: 12-pin connector
SinCos encoder: 12/17-pin
Brake (as an option) Main connection
Thermal sensor Resolver: Control connection
SinCos encoder: Main connection
Thermal motor protection (EN60034-11) Thermal sensor KTY84 in stator winding
Winding insulation (EN 60034-1) Thermal class F
Ambient temperature 0°C... +40°C
Altitude (EN 60034-1) ≤ 1000 m above sea level
Intermediate storage -30°C…+60°C (+85°C, see Section 2.5)
Bearings Rolling-contact bearings with grease lubrication
Calculated bearing life 20,000h (approximate value)
Vibration severity (EN 60034-14) Class A (previously N)
Vibration-resistant (EN 60068-2-6) Radial 3g (10 Hz to 100 Hz)
Axial 0.5g (10 Hz to 100 Hz)
Holding brake Option
Actual speed encoder Standard: 2-pole resolver
(High-quality version on request)
Optional: SinCos encoder
For additional technical data, please refer to technical product list DSD 45-100, which is available
from our website: www.baumueller.de/e_index.htm - Download- Technical documentations
Please request the relevant documentation if necessary.
