Baumuller DSD 45 User Manual

TAM 00621 20
DSD 45-100 05/2007
Three-phase synchronous motor English
Signal connection: Resolver with KTY 84 – Pin assignment
Pin Signal
View on contact side
of the female connector
1
2
3
4
5
6
7
8
9
10
11
12
cos -
sin –
sin +
K-
cos +
K+
Ref +
Ref -
Signal connection: SRS/SRM50 SinCos encoder (made by SICK) – Pin assignment
Pin Signal
View on contact side
of the female connector
1
2
3
4
5
6
7
8
9
10
11
12
ref cos
+ 485
sin
ref sin
- 485
cos
Screening
Gnd
+ U
Other encoder types: Pin assignment in accordance with enclosed wiring diagram/tech. documentation
