This document provides assembly instructions for the "0024 King Bed." It is a comprehensive guide detailing the components, hardware, and step-by-step process required to construct the bed frame.

Function Description:

The 0024 King Bed is a piece of furniture designed to support a king-sized mattress, providing a stable and elevated sleeping surface. Its primary function is to serve as the structural foundation for a bed, ensuring comfort and durability. The design appears to be a platform bed, as indicated by the inclusion of bed slats, which typically eliminate the need for a box spring. The bed frame consists of a headboard, footboard, side rails, and a central support system, all working together to create a robust structure.

Important Technical Specifications (Derived from Parts List):

Bed Size: King Bed (as indicated by the product name).
Main Structural Components:
- Headboard: Composed of two Headboard Panels (A) and two Headboard Posts (J & K).
- Footboard: Composed of one Footboard Panel (B) and two Footboard Posts (L & M).
- Side Rails: Two Left Hand Side Rails (C) and two Right Hand Side Rails (D). The presence of two of each suggests a design where the side rails might be composed of multiple segments or that the "left hand" and "right hand" refer to the orientation when facing the bed from the foot.
- Bed Slats: Four Bed Slats (E) are provided, crucial for mattress support.
- Support System:
  - Four Headboard Support Bars (F) are used to reinforce the headboard panels.
  - Two Center Support Legs (G) provide central stability.
  - Eight Support Legs (H) are distributed along the bed frame, likely under the side rails and possibly the footboard.
Hardware Specifications: The manual details various types and quantities of bolts, nuts, washers, and other fasteners, indicating the robust nature of the connections.
- JCB (Joint Connector Bolt) Sizes:
  - M6 x 90mm JCB (1): x 4
  - M6 x 60mm JCB (2): x 8
  - M6 x 40mm JCB (3): x 8
  - M6 x 35mm JCB (4): x 4
  - M6 x 30mm JCB (5): x 24
  - M6 x 20mm JCB (6): x 8
  - M6 x 15mm JCB (7): x 4
- Nuts: Barrel Nut (8): x 12
- Dowels: Wood Dowel (M10 x 40mm) (9): x 2
- Washers:
  - Spring Washer (10): x 24
  - Flat Washer (11): x 24
- Tools: Allen Key (12): x 1 (included for assembly)
- Brackets: Bracket (2005) (13): x 2
- Adjustable Feet: Adjustable Foot (14): x 8 (These are likely for the support legs to allow for leveling on uneven floors).

Usage Features:

Assembly Requirement: The bed is delivered unassembled and requires manual construction.
Two-Person Assembly: The instructions explicitly state "Use 2 People" for assembly, suggesting that some steps may involve handling large or heavy components that are difficult for one person to manage alone. This also implies that having an extra set of hands can prevent damage to parts and ensure proper alignment.
No Power Tools: A critical warning is provided: "Note: Do not assemble using power tools. This can cause the bolts to be overtightened." This highlights the importance of manual assembly to prevent stripping screws, cracking wood, or otherwise damaging the bed frame components. Manual tightening allows for a better feel of the appropriate torque, ensuring secure but not excessive fastening.
Platform Bed Design: The inclusion of bed slats (E) suggests a platform bed design, which typically means a box spring is not required. This simplifies the bedding setup and can offer a more modern aesthetic.
Support System: The multiple support legs (G, H) and headboard support bars (F) indicate a design focused on providing robust and stable support for the mattress and occupants, distributing weight evenly across the frame. The adjustable feet (14) further enhance stability by allowing the bed to be leveled on various floor surfaces, preventing wobbling.
Modular Construction: The bed is built from distinct panels (headboard, footboard), side rails, and support elements, which are then connected using a variety of bolts and nuts. This modularity simplifies manufacturing, packaging, and allows for easier replacement of individual components if needed.
Clear Labeling: All parts and hardware are clearly labeled with letters (A-M) and numbers (1-14) respectively, making it easy to identify and use the correct components during assembly.

Maintenance Features:

Manual Tightening: The instruction to avoid power tools for assembly indirectly contributes to maintenance. By manually tightening bolts, there's less risk of stripping threads or damaging components, which could lead to premature wear or instability. This ensures the initial assembly is sound, reducing the need for early repairs.
Adjustable Feet: The adjustable feet (14) are a key maintenance feature. They allow users to level the bed, which can prevent stress on the frame caused by uneven weight distribution on sloped floors. This helps maintain the structural integrity of the bed over time and prevents creaking or wobbling.
Component-Based Design: Should a specific part of the bed frame (e.g., a side rail, a support leg) become damaged, the modular design might allow for easier replacement of individual components rather than requiring the purchase of an entirely new bed. However, the availability of replacement parts would depend on the manufacturer.
Regular Inspection: While not explicitly stated, the nature of assembled furniture implies a need for periodic inspection of all bolted connections to ensure they remain tight. Over time, normal use can cause bolts to loosen, and re-tightening them manually (as per the initial assembly instructions) would be a standard maintenance practice to ensure the bed's stability and longevity.
Material Durability (Inferred): The use of various types of bolts and wood dowels suggests a construction method designed for durability. The specific materials (e.g., type of wood, metal for hardware) are not detailed in this document but are crucial for long-term maintenance. Assuming standard furniture-grade materials, the bed should withstand regular use with proper care.

Baxton Studio MG0024 - Page 4
