39
ENUSER’S MANUAL BR40
7. CONFIGURATION
The viewer has 6 settings that can be set by the user, in addition to a method for entering the calibration section.
STEPS DESCRIPTION
1
To set up the parameters press the key
.
2
The display will show the first function:
F0 H-L
3
If you press the key , will scroll across the other functions
4
If you press the key you are able to configure the function.
5
It may be necessary to use
or set a value using the key to change the active digit.
Use the key
to increase a digit
Press the key
to enter the value.
Use the key
To leave the setting as it was.
FOR EXAMPLE, when the display shows “
F0 H-L
” press the key
to start.
The display will show “
SET Lo
”, press the key
to establish the minimum limit, or press To move to the next parameter, “SET HI”
to set the maximum limit.
After pressing the key
to set a limit, use the arrow keys to change the flicker digit and then use the key To increase the flicker
digit. Continue with the next digit, and establish the necessary quantities.
When all digits have been configured, press the key
to store the value. The display will return to the parameter that was just configured, for
example “SEt”. Continue until you reach another parameter if its necessary or press the key To return to the normal weight.
7.1 CONFIGURATION OF FUNCTIONS MENU
You can access to the menu
from the user moder normal weight
MENU SUB-MENU description
F0 H-L
SEt Lo
Set a value as the lower limit
SEt HI
Set a value as the upper limit
